Product Features
Rear Panel Components
Rear Panel Components
1 Power Cord Connector 8
l
Parallel Connector
2 Voltage Select Switch 9
c
Monitor Connector
3
b
PS/2 Mouse Connector -
Y
Headphone/Line-Out Connector
4
a
PS/2 Keyboard Connector q
j
Line-In Audio Connector
5
o
Universal Serial Bus (USB) w
g
Microphone Connector
6
m
Serial Connector e
c
Digital Video Interface (DVI–D)
Monitor Connector
7
n
RJ-45 Network Connector
✎
Arrangement and number of connectors may vary by model.
If a PCI graphics card is installed, the connectors on the card and the system board may be
used at the same time. Some settings may need to be changed in F10 setup to use both
connectors. For more information about Boot Order, refer to the Computer Setup (F10) Utility
Guide on the Documentation CD.
The DVI–D connector will only work with flat panel displays.
