Drive Positions
Figure 2-15 Drive Positions
1 Two 5.25-inch external drive bays for optional drives (optical drives shown)
2 Two 3.5-inch external drive bays for optional drives (diskette drives shown)
3 Two 3.5-inch internal hard drive bays
To verify the type and size of the storage devices installed in the computer, run Computer Setup. Refer
to the Computer Setup (F10) Utility Guide on the Documentation and Diagnostics CD for more
information.
26 Chapter 2 Hardware Upgrades ENWW
