18. Lock any security devices that were disengaged when the access panel was removed.

19. Reconfigure the computer, if necessary.

Drive Positions

Figure 4-16 Drive Positions

Table 4-2 Drive Positions

1 3.5-inch internal hard drive bay

2 3.5-inch drive bay for optional drives (media card reader shown)

3 5.25-inch drive bay for optional drives (optical drive shown)

NOTE: The drive configuration on your computer may be different than the drive

configuration shown above.

To verify the type and size of the storage devices installed in the computer, run Computer Setup.

Drive Positions 105
