14. To place the hard drive carrier back in the chassis, align the guide screws with the slots on the
drive bay, drop the carrier straight down into the drive bay (1), and press the handle on the
carrier all the way down (2) so that the drive is properly seated and locked in place.
Figure 5-21 Installing the Hard Drive Carrier
15. Replace the optical drive and reconnect the cable on the back of the optical drive.
16. Replace the computer access panel.
17. If the computer was on a stand, replace the stand.
18. Reconnect the power cord and turn on the computer.
19. Lock any security devices that were disengaged when the computer cover or access panel was
removed.
NOTE: No configuration of the SATA hard drive is necessary; the computer automatically
recognizes it the next time you turn on the computer.
146 Chapter 5 Ultra-Slim Desktop (USDT) Hardware Upgrades
