3. Remove the adhesive strip that secures the thermal sensor to the top of the hard drive (1) and

move the thermal sensor away from the carrier (2).

Figure B-2 Removing the Thermal Sensor

4. Remove the four screws from the bottom of the hard drive carrier.

Figure B-3 Removing the Security Screws

159
