DP – DVI/HDMI DP VGA VGA will be inactive
DP – DVI/HDMI DP – VGA VGA VGA will be inactive
DP – DVI/HDMI DP – dlDVI VGA VGA will be inactive
DP – DVI/HDMI DP – DVI/HDMI VGA VGA will be inactive
Connection Type Description
DP Direct connection to a DisplayPort monitor
DP-VGA VGA monitor connected with a DP to VGA adapter
DP – dlDVI Dual link DVI monitor connected with a DP to dlDVI-D adapter
DP – DVI/HDMI DVI-D or HDMI monitor attached using a DP to DVI-D or DP to HDMI adapter
VGA Direct connection to a VGA monitor
Notes :
DisplayPort #2 is restricted to modes 1900x1200 and lower when any display is connected to the VGA Port
If active, the VGA output is limited to modes of 1900 x 1200 and lower when any display is connected to the DisplayPort #2
Not a recommended configuration since the dP to dlDVI adapter is intended for dual link DVI monitors which have > 1920 x 1200
resolution
May not be an optimum configuration due to DP to VGA/DVI/HDMI adapter limitations; better configuration achieved by
swapping DisplayPort #1 and DisplayPort #2 connections.
The DP to VGA adapter is limited to resolutions of 1920 x 1200 and below
The DP to DVI and HDMI adapters are limited to resolutions of 1920 x 12 and 1920 x 1080, respectively
The DP to dlDVI adapter is intended to only be used with monitors that require dual link DVI source
SLOTS
USDT SFF CMT
PCI Express Mini Card 1 each N/A N/A
MXM 1 each N/A N/A
mSATA 1 each N/A N/A
Conventional PCI
Revision 2.3
5-volt
N/A 1 each
2.5” low profile
6.6" length
25W max. power
3 each
4.2” full height
6.6” length
25W max. power
PCI Express x1 N/A 1 each (2.0)
2.5” low profile
6.6” length
10W max. power
1 each (2.0)
4.2” full height
6.6” length
10W max. power
QuickSpecs
HP Compaq Elite 8300 Business PC
Standard Features and Configurable Components (availability may vary by country)
DA - 14268 North America — Version 41 — November 22, 2013 Page 14
