Memory Configurations: Small Form Factor / Convertible Minitower
Slot 1 is black and must always be populated. Not all memory configurations possible are represented below.
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory may not be available due to
system resource requirements. Addressing memory above 4 GB requires a 64-bit operating system.
Total Memory Socket
Channel A (black) Channel B (black)
1 (black) 2 (white) 3 (white) 4 (white)
2 GB 2 GB unpopulated Unpopulated unpopulated
4 GB
(dual channel)
2 GB unpopulated 2 GB unpopulated
8 GB
(dual channel)
2 GB 2 GB 2 GB 2 GB
16 GB
(dual channel)
4 GB 4 GB 4 GB 4 GB
QuickSpecs
HP Compaq Elite 8300 Business PC
Technical Specifications – Memory
DA - 14268 North America — Version 41 — November 22, 2013 Page 49
