HP Compaq Elite 8300 Specification

512 MB of DDR3 dedicated on-board graphics frame buffer memory
AMD Radeon™ HD 6350 GPU
Conforms to full PCI Express 2.0A specification for low profile form factor (x16 lanes native PCI Express implementation)
Includes a DMS-59 to Dual VGA Y Cable
HDCP supported on DVI outputs ( DVI Requires optional kit DL139A)
DirectX 11.1 support in hardware for optimal performance in DX11.1 applications.
AMD Avivo technology for improved image and video playback.
OpenGL 4.0 support in hardware for optimal performance with OpenGL applications
NOTE: The AMD Radeon HD 6350 PCIe x16 Graphics Card does not support Dual-link DVI capable monitors.
Form Factor
PCI Express x16 (generation 2.0)
Low Profile, half length, 2.3" x 6.6"
Full height bracket utilized when configured to CMT
Graphics Controller AMD HD 6350 GPU
Output Connector
Single DMS-59 connector
Supports dual analog displays with included DMS-59 to dual VGA Y cable.
Also supports dual digital displays with an optional DMS-59 to dual DVI cable.
Core Clock 650MHz
Memory Clock 800MHz
Memory Frame Buffer 512MB, DDR3, 64-bit wide
Bus Type PCI Express x16, Generation 2.0
Max. Vertical Refresh 85Hz
Display Support Integrated 400MHz RAMDAC
Display Max. Resolution
Digital 1900 x 1200
Analog 2048 x 1536
Max. Power Consumption 19.9W
Supported Graphics APIs
HDCP supported on DVI output using optional DMS-59 to dual DVI cable.
DirectX 11.1 support in hardware.
OpenGL 4.0 support in hardware.
Display Resolutions and Refresh Rates
NOTE: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP
Resolution Maximum Refresh Rate (Hz)
Analog Digital
640 x 480 85 60
800 x 600 85 60
1024 x 768 85 60
1280 x 720 85 60
1280 x 1024 85 60
1440 x 900 75 60
1600 x 1200 85 60
1680 x 1050 75 60
1920 x 1080 85 60-R
1920 x 1200 85 60-R
QuickSpecs
HP Compaq Elite 8300 Business PC
Technical Specifications - Graphics
DA - 14268 North America — Version 41 — November 22, 2013 Page 23

HP Compaq Elite 8300 Specifications

General

Operating temperature (T-T)	10 - 35 °C
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
HDD size	3.5 \
Dimensions (WxDxH)	178 x 445 x 448 mm
Microphone in	Yes
HDMI ports quantity	0
PS/2 ports quantity	2
USB 2.0 ports quantity	6
PCI slots	3
Chassis type	Mini-Tower
Product type	PC barebone
Product color	Gray
Audio system	HD
Motherboard chipset	Intel® Q77 Express
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Power supply	320 W
Operating system installed	No
Processor model	-
Processor family	Intel

Weight and Dimensions

Weight	11200 g
