6. Slide the keyboard back until its top edge rests on the display assembly (2).
7. Release the zero insertion force (ZIF) connector (1) to which the keyboard cable is attached.
8. Disconnect the cable (2), and then remove the keyboard.
9. Remove the keyboard.
Reverse this procedure to install the keyboard.
52 Chapter 4 Removal and replacement procedures
