Page #5 background imageLoading...
Page #5 background image
5
Appendix A: System ROM versions
Determining the ROM version using Setup
Note
The ROM versions listed in this document are current as of the white paper
publication date.
Use the HP Setup utility or HP Diagnostics for Windows to determine the system ROM version. Refer to
Table 2 for the current ROM version.
Table 2 ROM versions
Portable family Current ROM version
HP Compaq nc4000/nc4010 F.2A
HP Compaq nc6000 F.0F
HP Compaq nc8000 F.0F
HP Compaq nx5000 F.0B
HP Compaq nx7000/7010 F.42
HP Compaq nx9000 KG.M1.17
HP Compaq nx9005 KA.M1.59
HP Compaq nx9010 KH.F.23
HP Compaq nx9105 F.12
HP Compaq nx9100/9110 F.21
! A block cursor displays in the upper right corner of the screen during startup.
1. Press F10 when the block cursor displays.
2. Scroll down using the down arrow key to highlight View System Information and press Enter.
The System Information prompt appears.
3. Make note of the ROM date and compare it to the date in Table 2.
4. Press Esc to exit the ROM information screen.
5. Scroll down using the down arrow key until Exit without Saving Changes is highlighted.
Press Enter.
6. Press F10 to confirm exiting the HP Utilities.
7. If the ROM requires upgrading and the ROMPaq diskette is not available, see “Creating a
ROMPaq Diskette” in this appendix. Otherwise, proceed to “Upgrading the ROM.”
Determining the ROM version using HP Diagnostics for Windows
1. If Diagnostics for Windows is installed on the notebook PC, the following steps can be used to
determine the ROM version.
2. Click StartSettingsControl Panel.
3. Double-click the Diagnostics icon.
4. Click the system icon (the leftmost icon on the icon bar near the top of the window).
5. Scroll through the list until the System ROM information appears. Make note of the ROM version
and compare it to listings in Table 2.

Other manuals for HP Compaq NC4000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq NC4000 and is the answer not in the manual?

HP Compaq NC4000 Specifications

General IconGeneral
Processor cache1 MB
Processor model-
Processor frequency1.4 GHz
Processor cache typeL2
Processor front side bus400 MHz
Processor core voltage (AC)0.956 - 1.388 V
HDD speed5400 RPM
HDD interfaceUltra-ATA/100
Optical drive typeNo
Card reader integratedYes
Total storage capacity40 GB
Compatible memory cardsSD
Number of HDDs installed1
Pixel pitch0.264 x 0.264 mm
Display diagonal12.1 \
Display brightness130 cd/m²
Display resolution1024 x 768 pixels
Native aspect ratio4:3
Display number of colors16.78 million colors
TypePC
Modem speed56 Kbit/s
Power supply typeAC/DC
Power requirements90 - 264V, 47/63Hz
Wireless technologyWi-Fi
Graphics card familyAMD
Compatible operating systemsWindows XP
Compliance industry standardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Memory slots2x SO-DIMM
Internal memory0.25 GB
Internal memory typeDDR-SDRAM
Maximum internal memory1 GB
Audio systemPS
Pointing deviceTouchpad
Cabling technology10/100/1000Base-T(X)
Networking featuresGigabit Ethernet
Operating system installedWindows XP Professional
TV-out typeS-Video
Charging port typeDC-in jack
USB 2.0 ports quantity2
Firewire (IEEE 1394) ports0
Cable lock slot typeKensington
AC adapter power65 W
Number of battery cells6
Operating shock40 G
Operating altitude0 - 3048 m
Non-operating shock240 G
Operating vibration0.5 G
Non-operating altitude0 - 9144 m
Non-operating vibration1 G
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
CertificationUL, CSA, VDE/TUV
Product colorBlack, Silver
Country of originChina
Weight and Dimensions IconWeight and Dimensions
Depth233.7 mm
Width279.4 mm
Height27.9 mm
Weight1590 g
