Product Description
The external components on the bottom of the notebook are
shown below and described in
Table 1-8.
Bottom Components
Table 1-8
Bottom Components
Item Component Function
1 Primary battery bay Holds the primary battery pack.
2 Primary battery locking
latch
Secures the primary battery pack into
the battery bay.
3 Docking connector
(full-featured models only)
Connects the notebook to an optional
docking device.
