R
emo
v
al and Replace
ment Pr
ocedure
s
Maintenance and S
ervi
ce Guide
6–11
3.
Slide the Bluetooth board
1
out of the clip in the hard dri
ve
compartment.
4.
Disconnect the Bluetooth board cable
2
from the board.
R
emo
v
ing the Blueto
oth Boar
d
Re
v
erse the abov
e procedure to install a Bluetooth board.
