Removal and Replacement Procedures
Maintenance and Service Guide 6–43
6.21 Speaker
1. Prepare the computer for disassembly (Section 6.3),
and then remove the following components:
a. Hard drive (Section 6.4)
b. Memory module/Mini PCI compartment cover
(Section 6.7)
c. Optical drive (Section 6.9)
d. Keyboard (Section 6.10)
e. Switch cover (Section 6.11)
f. Display assembly (Section 6.19)
g. Top cover (Section 6.20)
Speaker Spare Part Number Information
Speaker 378237-001
