HP Compaq nx6110 User Manual

7–4 Maintenance and Service Guide
Specifications
Table 7-3
15.0-inch, XGA, TFT Display
Dimensions
Height
Width
Diagonal
30.0 cm
22.9 cm
38.1 cm
11.8 in
9.0 in
15.0 in
Number of colors Up to 16.8 million
Contrast ratio 250:1
Brightness 150 nits typical
Pixel resolution
Pitch
Format
Configuration
0.264 × 0.264 mm
1024 × 768
RGB vertical stripe
Backlight Edge lit
Character display 80 × 25
Total power consumption 5.5 W
Viewing angle +/-35° horizontal, +15/-35° vertical
typical

HP Compaq nx6110 Specifications

General

Storage	40 GB to 80 GB HDD
Optical Drive	DVD-ROM or DVD/CD-RW combo
Battery	6-cell Lithium-Ion
Battery Life	Up to 4 hours
Weight	2.7 kg (6.0 lbs)
Processor	Intel Pentium M or Intel Celeron M
RAM	Up to 2 GB DDR SDRAM
Display	15.0-inch XGA TFT
Graphics	Intel GMA 900
Operating System	Windows XP Professional
Networking	10/100 Ethernet
Ports	USB 2.0, VGA, headphone, microphone, RJ-11, RJ-45
Expansion Slots	1 x Type I/II PC Card
