Illustrated Parts Catalog
Maintenance and Service Guide 4–19
Screw Kit (includes the following screws; refer to
Appendix C, “Screw Listing,” for more information on
specifications and usage
378235-001
■ Hex socket HM5.0×9.0 screw lock
■ Phillips PM2.5×13.0 spring-loaded
screw
■ Phillips PM2.5×4.0 shoulder screw
■ Phillips PM2.5×4.0 screw
■ Phillips PM2.0×8.0 shoulder screw
■ Phillips PM2.0×7.0 screw
■ Phillips PM2.0×4.0 screw
■ Phillips PM2.0×3.0 screw
■ Phillips PM1.5×4.0 screw
■ Phillips PM1.5×3.5 screw
■ Torx8 T8M2.0×9.0 screw
■ Torx8 T8M2.0×4.0 screw
■ Torx8 T8M2.0×2.0 screw
Table 3-5
Miscellaneous (Not Illustrated)
Spare Part Information
(Continued)
Description
Spare Part
Number
