Screw Listing
Maintenance and Service Guide C–3
Phillips M2.5×13.0 Screw Location
Table C-2
Phillips PM2.5×13.0 Spring-loaded Hard Drive Retention Screw
Color Qty. Length Thread
Head
Width
Silver 1 13.0 mm 2.5 mm 5.5 mm
Where used:
1 screw that secures the hard drive to the notebook (screw is captured on the
hard drive frame by a C clip; documented in Section 5.3)
mm
