5–6 Maintenance and Service Guide
Removal and Replacement Procedures
b. Slide and hold the battery pack lock latch 1 to the right.
c. Slide the battery pack release latch 2 to the right. (The
battery pack disengages from the notebook.)
d. Slide the battery pack straight back 3 and remove it.
Removing the Battery Pack
Reverse the above procedure to install the battery pack.
