5–14 Maintenance and Service Guide
Removal and Replacement Procedures
2. Loosen the PM2.0×5.0 screw 1 that secures the Mini PCI
compartment cover to the computer.
3. Lift the rear edge of the Mini PCI compartment cover 2, and
then swing it forward.
4. Remove the Mini PCI compartment cover.
✎
The Mini PCI compartment cover is included in the
Miscellaneous Plastics Kits, spare part numbers 367765-001
(for use on HP Pavilion dv1000 models) and 367766-001 (for
use on HP Compaq nx4800 and
Compaq Presario V2000 models).
Removing the Mini PCI Compartment Cover
