Step 1. Inserting the Battery
1. Unlock and open the battery/memory card compartment (feature no. 16 on page 2) on the bottom
of the camera as shown below. To unlock the door slide the release slider (step 1) towards the back
of the camera. At the same time slide the door (step 2) to the right.
2. Insert four AA batteries into the cavities with
the alternating battery orientation exactly as
shown in the figure to the right. Note:
inside each battery cavity there is a small
decal that depicts proper battery orientation.
3. Close the battery/memory card compartment
door and slide it back to its closed position.
The slider will click into its locked position.
Step 2. Inserting an SD/SDHC/SDXC Memory Card
1. Unlock and open the Battery/memory card
compartment at the bottom of the camera as
described in the previous section.
2. Insert an SD, SDHC, or SDXC card into the
memory card slot with the contact pins facing
the back side of the camera as shown.
3. Push the memory card into the memory slot
until it clicks into place.
4. Close and lock the Battery/memory card
compartment door as described in the
previous section.
NOTE: To remove the memory card: Gently push the card until it pops out. Pull the card out and lock the battery cover.
