Installing the New Optical Drive
NOTE: If you are installing an optical drive in a bay that did not previously have a drive in it, you must
remove the access panel and the bezel blank covering the opening of the bay before proceeding. Follow
the procedures in
Removing the Computer Access Panel on page 10 and Removing a Bezel Blank
on page 13.
1. Attach the release latch to the new optical drive. Refer to Preparing the New Optical Drive
on page 26.
2. Align the optical drive with the opening in the front bezel. Make sure the back of the optical drive
is being inserted first and the release latch is on the inner side of the drive.
3. Slide the optical drive into the computer through the front bezel. However, do not slide it all the way
in until it locks. Leave it approximately 6 mm (1/4 inch) short of the fully-inserted locked position to
allow room to connect the cable.
Figure 2-19 Inserting the Optical Drive
4. Connect the cable to the rear of the optical drive (1), then slide the drive the rest of the way into
the bay so that it locks in place (2).
Figure 2-20 Connecting the Cable and Locking the Drive in Place
ENWW Replacing the Optical Drive 27

HP dc7800 series Specifications

General

Chipset	Intel Q35 Express
Memory	Up to 8 GB DDR2 SDRAM
Audio	Integrated High Definition Audio
Processor Options	Intel Core 2 Duo
Graphics	Intel Graphics Media Accelerator 3100
Optical Drive	DVD-ROM
Network	Integrated Intel Gigabit Ethernet
Ports	USB 2.0
Expansion Slots	PCI, PCIe x1, PCIe x16
Operating System	Windows Vista, Windows XP
Power Supply	240W
Form Factor	Small Form Factor (SFF), Convertible Minitower (CMT)
