Front Panel Components
Drive configuration may vary by model.
Figure 1-2 Front Panel Components
Table 1-1 Front Panel Components
1 Optical Drive 5 System Power LED
2 Headphone Connector 6 Hard Drive Activity Light
3 Microphone Connector 7 USB (Universal Serial Bus) Ports
4 Dual-State Power Button
NOTE: An optical drive is a DVD-ROM drive, a DVD-CDRW Combo drive, or a SuperMulti LightScribe drive.
2 Chapter 1 Product Features ENWW
