HP DESIGNJET 3D - Control Panel

Control panel 5
Control panel
Figure 4 Control Panel
1 Cleaning tank level button
2 Full cleaning tank level LED
3 Half cleaning tank level LED
4 Cycle length button
5 Long cycle length LED.
6 Medium cycle length LED.
7 Short cycle length LED.
8Progress LEDs
9 Process error LED
10 Start cycle button
11 C a n c e l b u t t o n
1
2
4
3
8
9
7
10
5
6
11
Overview
