HP Designjet 4000 Series

4-1
hp designjet 4000 series printer service manual
Service Tests and
Utilities
4
Introduction 4-2
Diagnostics - Self Test 4-2
Service Tests (Diagnostics) 4-3
Entering the Service Tests Menu 4-5
1. Scan Axis Test 4-7
2. Media Drive Test 4-12
3. Electronics Module Test 4-17
4. Carriage Assembly Test 4-27
5. Sensors Test 4-28
6. Ink Delivery System Test 4-32
7. SVS/Aerosol Fan Test 4-33
8. Air Pump System Test 4-34
9. Vacuum Fans Test 4-35
10.1 Others >>> Bag Broken Recovery 4-36
10.2 Others >>> IO Information 4-39
10.3 Others >>> Unit Information 4-40
10.4 Others >>> Check Ink Supplies 4-42
11. EEROM Reset 4-44
12. Set Unit Configuration 4-46
13. Error 71:19 Recovery 4-47
I/O Tests 4-49
Service Utilities 4-51
Entering the Service Utilities Menu 4-52
1. Turn Drive Roller 4-54
2. Prime Tubes 4-56
3. Set SN 4-60
4. Reset Life Counters 4-61
5. Diagnostic Print 4-63
6. Sleep Mode 4-64
7. Replace Cutter 4-65
8. Set RTC Clock 4-66
9. Carriage Setup 4-67
