HP Designjet 4000 Series

9. Ensure the blue paper stop is pushed in as far as it will go, without using excessive force.
10. With the blue paper stop on the left, slide the spindle into the printer left and then right as shown by
the arrows 1 and 2.
11. To make sure that the right end of the spindle is in place, check that the spindle lever is in its top
position (horizontal). You can move the lever yourself if necessary.
If you are a regular user of different paper types, you can change rolls more quickly if you pre-load rolls
of different paper types on different spindles. Extra spindles are available for purchase.
Load a roll into the printer [4000]
NOTE This topic applies to the HP Designjet 4000 Printer series only.
To start this procedure you need to have a roll loaded on the spindle. See
Load a roll onto the
spindle [4000].
20 Chapter 3 How do I... (paper topics) ENWW
How do I... (paper topics)
