Load a roll onto the spindle [4500]
NOTE This topic applies to the HP Designjet 4500 Printer series only.
1. Push the grey button and remove the blue paper stop from the spindle.
2. If your roll has a three-inch cardboard core, ensure that the core adaptors supplied with the printer
have been installed. See below:
3. The roll may be long and heavy; rest the spindle horizontally on a table and load the roll on the
table. Bear in mind that you may need two people to handle it.
4. Slide the new roll onto the spindle. Make sure the paper type is oriented as shown. If it is not,
remove the roll, turn it 180 degrees and slide it back on to the spindle.
NOTE There is also a diagram on the outside face of each paper stop showing the
correct orientation.
ENWW Load a roll onto the spindle [4500] 29
