HP Designjet 4000 Service Manual

2
hp designjet 4000 series printers service manual
Using this Manual
Purpose
This Service Manual contains information necessary to test, calibrate and
service:
 hp designjet 4000 printer (Model Q1273A)
 hp designjet 4000ps printer (Model Q1274A)
For information about using these printers, refer to the corresponding User
and Quick Reference Guides.
Readership
The procedures described in this Service Manual are to be performed by HP
Certified service personnel only.
Part Numbers
Part Numbers for Printer options, accessories and service parts are located
in Chapter 7.
Conventions
A small arrow ⇒ is used to indicate other parts of the Service Manual where
you can find information related to the topic you are consulting.

HP Designjet 4000 Specifications

General

Print Technology	Thermal Inkjet
Maximum Print Width	42 inches
Memory	256 MB
Ink Types	Dye-based (color), pigment-based (black)
Number of Ink Cartridges	4
Media Types Supported	Bond and coated paper, technical paper, film, photographic paper, backlit
Interface	USB 2.0, Ethernet
Maximum Print Size	42 inches (1066.8 mm) wide, unlimited length
Roll Maximum Outer Diameter	13.5 cm
Roll Width	24 to 42 inches
Hard Disk Capacity	40 GB
Operating Systems	Windows, Mac OS X
