11. Fix the right leg to the cross-brace using four screws on the inner side of the leg.
12. Fix the right leg to the cross-brace using two screws on the outer side of the leg.
13. Position a foot on the left leg. There are pins to help you to position the foot
correctly.
Note Do not remove the anti-slip material from the wheel.
Chapter 2
20
How do I assemble the printer?
