C
Remove the first tray containing the parts for the bin.
When you are unpacking the stand
assembly, you will see that there
is anti-slip material around two
of the wheels on the feet.
DO NOT REMOVE this material yet.
From the second tray, remove the two boxes marked with
L and R. Place them on the floor as shown.
Remove the second tray from the stand and bin assembly
box. This tray contains the stand legs.
Lower the cross-brace on to the L and R boxes.
You now need to identify which is the left and the right side
of the cross-brace.
Now you will need the bag of screws and the
screwdriver provided. You may notice that the
screwdriver is slightly magnetic.
Two holes
Left
Right
One hole
Remove the two packing pieces.
1312 14 15
1716 18 19
