8-112
Removal and Installation
HP Designjet 4500 Printer Series Service Manual
4. Remove the L-Plate.
5. Remove the Mylar Strip.
When installing the Mylar Strip
make sure that from the rear of
the printer, the Mylar Strip is
aligned to the left against the
plastic stop and that there are no
bubbles in the Mylar Strip.
To Next Page
