Parts and Diagrams
276 Chapter 7 Parts and Diagrams
Left Hand Assemblies
Reference
on
Figure
HP Part
Number
Part Description Size
Page
a
a. Refers to the page in the Removal and Installation Chapter (if applicable)
1
CH955-67028 Cartridge Trays All
548
2
CH955-67014
Lower Ink Supply Station (without APS
Assembly but including Cartridge Tray)
All
388
3
CH955-67013
Upper Ink Supply Station (without APS
Assembly but including Cartridge Tray)
All
388
4
CH955-67024 Left Scan-Axis Bracket All
N/A
5
Q1273-60245 ISS to Cartridge Cable All
N/A
6
Q6651-60300
APS Assembly
b
b. Including Pump, Holder, and Relief Valve
42-inch
395
Q6652-60117
60-
inch
7
Q6651-60272 Color Sensor Actuator ALL
492
8
CH955-67054 ISS PCAs All
9
CH955-67084 Shutter Bump (actuator) All
10
CH955-67091 Cable Plate and Cover All
11
CH955-67096
Paper Jam Sensor (Includes Carriage
Reflector & cable)
All
12
-Paper Jam sensor cable All
13
CH956-67094 Cable Plate Bundle (cables) 42-inch
CH956-67035 Cable Plate Bundle (cables)
60 -
inch
To Next Page
