290 Chapter 7 Parts and Diagrams
Media Path Assemblies
Reference
on
Figure
HP Part
Number
Part Description Size
Page
a
a. Refers to the page in the Removal and Installation Chapter (if applicable)
1
CH955--67011
Center Platen
b
b. Includes the Attachment Screw Retainer
42-inch
538
CH956-67001
60-
inch
2
CH955-67039
Output Platen
42-inch
533
CH956-67004
60-
inch
3
CH955-67065 Output Roller Support (& Pins) All
552
4
Q1273-60103 Input Roller Lever All
550
5
Q1273-60058
Input Roller
42-inch
550
Q6652-60114
60-
inch
6
Q6651-60270 OMAS Module All
424
7
Q6651-60269 OMAS Cable All
439
8
CH955-67066 TOMAS Assembly All
431
To Next Page
