Front Panel 353
Removal & Installation
Front Panel
Removal
1. Remove the Right Cover
⇒
See page 319
.
2. Remove the Right Connector Cover
⇒
See page 341.
3. Disconnect the Front Panel Cable from the Interconnect
PCA.
4. Disconnect the Ferrite clip (located on the rear of the
Electronics Module) from the front of the Printer.
5. Move the Front Panel Cable (including the ferrite) out of
the Electronics Module.
WARNING!: Switch off the printer and remove the power cable.
To Next Page
