384 Chapter 8 Removal & Installation
Removal & Installation
22.Remove the Ink Supply Tubes and Trailing Cable from
the Printer.
Installation of the Ink Supply Tubes and Trailing Cable
NOTE: After installing the NEW Ink Supply Tubes and Trailing Cable, reset the life counter
“4.5.2 Tubes/Trailing Cable”
⇒
page 200.
NOTE: When installing the Ink Supply Tubes and Trailing Cable on to the Top Cover, take note
of the of the two red marks on the Ink Supply Tubes. These two red marks should be aligned with
the first slot in the Top Cover as this will help with the rest of the installation.
To Next Page
