398 Chapter 8 Removal & Installation
Removal & Installation
16. Unroute the APS 2 electrical connection from the
printer.
17. Disconnect both air tubes from APS 2.
18 . Remove one T-20 attachment screw from APS 1 (Top
unit).
19. Remove APS 2 (Bottom unit) from the printer.
1
2
NOTE: After installing the NEW APS pumps,
reset the life counter “4.4.1 APS cycles”
⇒
page 200.
