HP Designjet T7100 Mono

4. Put three drops of oil into each hole in the platen.
NOTE: Be careful not to spill oil onto the platen.
5. If oil spills onto the platen, wipe the platen clean by using the cloth that was supplied with the
maintenance kit.
6. Lower the printer window.
ENWW The platen rollers squeak 167
