Load a roll into the printer
1.
At the printer's front panel, select the
icon, and then select Paper load > Load roll.
2. Select the roll that you intend to load using the Up and Down keys. The printer puts all rolls on standby.
3. If the selected roll is currently loaded, the printer automatically unloads it, printing the barcode if
Printing paper info is enabled (see
Printing paper info on page 36). Remove the unloaded roll.
4. If Printing paper info is not enabled, the front panel asks you to select the paper type (see
Supported
paper types on page 27).
5. Open the roll door with its blue handle when prompted by the front panel.
6. Check that the hubs are the correct size for the roll you want to load. If necessary, change them.
7. Move the left hub to the left by pressing the blue lever.
8. Put the roll into the cavity with the paper edge on the near side facing downwards.
ENWW Load a roll into the printer 29
