HP Designjet T7100 Mono

9. Insert the right side of the roll onto the right hub. Check that the roll is in contact with the disc.
10. Push the left hub onto the left end of the roll. Check that the hub disc is aligned with the green mark.
11. Check that there is no gap between the roll and either of the hubs.
30 Chapter 4 Handle the paper ENWW
