WARNING! Make sure that the printer wheels are locked (the brake lever is pressed down) to prevent the
printer from moving.
1.
At the front panel, select the
icon, then select Replace maintenance ctg.
2. The maintenance cartridge is located in a slot underneath the front panel, at the front of the printer.
Open the door.
3. The maintenance cartridge has a handle on the front. To remove the cartridge, press inward and upward
as indicated by the arrow, until the cartridge is released.
4. Lift up the maintenance cartridge to remove it from the slot, and slide it out.
See also Insert the maintenance cartridge on page 62.
ENWW Work with ink system components 61
