HP Designjet T7xx memory upgrade
This memory upgrade enables you to print particularly complex jobs. If you receive an “Out
of memory” error message when trying to print a job, you may need this upgrade. It
provides 6 GB of extra memory and can be plugged into one of the printer's USB ports.
This memory upgrade has been designed to be used with an HP Designjet 770 printer only,
and not with the HP Designjet T770 Hard Disk Version. It may be damaged if you attempt to
connect it to other devices.
How to install
Ensure that the printer is turned on.
Insert the USB dongle into the USB port behind the printer on the left-hand side.
The front panel displays, “Graphic Memory upgrade. Upgrading printer’s graphic
memory. Printer will need to be restarted during the process. Press OK to
continue or X to abort”.
If the USB dongle is not connected to the printer, the printer cannot use the 6 GB of extra
memory.
To check that the memory upgrade upgrade has been correctly installed, go to the main
menu on the front panel, Information icon/Printer Information and you should see
“Memory: 8GB”.
How to uninstall
o Printer on
o Remove the memory dongle from the printer
o Follow instructions on front panel
If you remove the USB when the printer is off, when you turn it on the front panel asks you
either to put it back and continue or to proceed with the uninstallation process.

HP Designjet T770 Specifications

General

Ethernet LAN	Yes
USB connector	USB Type-A
USB 2.0 ports quantity	1
Media thickness	> 0.3 mm
Roll top margin	5 mm
Custom media sizes	210 x 279 - 1118 x 1676 mm
Maximum print size	A0 (841 x 1189 mm)
Standard media sizes	A4; A3; A2; A1; A0
Maximum roll diameter	135 mm
Print margin cut-sheet	5 x 5 x 5 x 17 mm
Recommended media weight	60 - 328 g/m²
Media thickness (by paper path)	0.8 mm
Printing colors	Cyan, Magenta, Matte black, Photo black, Yellow
Maximum resolution	2400 x 1200 DPI
Page description languages	HP-GL/2, HP-RTL
Print speed (normal quality, A1)	103 pph
Print speed (color image, best quality, glossy paper)	2.8 m²/hr
Print time black and white line drawing (draft, metric A1 plain paper)	80 page/hour
Safety	EU (LVD & EN 60950-1), GOST
Functions	Print
Line width minimum	0.0024\
Printer management	HP Web Jetadmin
Acoustic power emissions	6.2 B(A)
Maximum media length (imperial)	66 \
Acoustic power emissions (standby)	44 dB
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	Energy Star; WEEE; EU RoHS; REACH; EuP; FEMP IPv6 Phase 1; USB 2.0
Built-in processor	Intel® Pentium® M
Storage drive type	No
Power requirements	100 - 240 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz), 2 A
Power consumption (typical)	120 W
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Recommended operating temperature range (T-T)	15 - 35 °C
Package weight	111000 g
Package weight (imperial)	244 lbs
Package dimensions (W x D x H)	75.98 x 30.16 x 30.7 \
Compatible operating systems	Windows 7 Home Premium/Professional/Ultimate; Windows Vista Home Premium/Business/Ultimate; Microsoft Windows XP (32-bit, 64-bit) Home/Professional, Server 2003 (32-bit, 64-bit), Server 2008 (32-bit, 64-bit; Novell NetWare 5.x, 6.; Mac OS X v10.4, v10.5, v10.6, Citrix XenApp, Citrix XenServer

Weight and Dimensions

Size (imperial)	69.7 \
Weight (imperial)	180 lb lbs
Dimensions (WxDxH)	1770 x 702 x 1050 mm
