HP DesignJet Z3200 Brochure & Specs

3
HP Designjet Z3200 PostScript printer at a glance
• Optimize use of media when printing several images
• Free-up your computer processing time
• Print 16-bit TIFF and JPEG images with HP Embedded Web Server’s
16- to 8-bit LCED color converter
• Calibrate your computer monitor
(i1 display calibration device included)
• Edit RGB and CMYK ICC profiles
• More color patches for more sophisticated ICC profiles
• Accurately achieve in-gamut colors and properly reproduce
out-of-gamut colors
• Print customized spot color simulation swatchbooks for the media of
your choice
Manage the printer remotely using HP Embedded Web Server:
• Send print jobs to the printer without having to open the image from an
application, from any computer (no driver needed).
• Easily manage your print job queue.
• Store jobs—with various print settings—on the printer for easy, frequent
re-prints without ripping
HP Professional PANTONE Emulation
With 95% coverage of PANTONE colors, you can produce
accurate spot-color proof prints for your design projects using
the HP Designjet Z3200 PostScript printer.
• Assign PANTONE color names to graphical elements in
your PS/PDF-capable design application, and have the
printer automatically generate matching in-gamut colors and
visually optimized equivalents for out-of-gamut colors, using
a specific spot color rendering intent not available from
standard ICC profiles
**
.
• Automatically create your own PANTONE swatch book
illustrating the closest available match to PANTONE colors for
the print medium selected. The printed color swatch comes
with a numerical indication of how closely colors match, and
the included device color values make it easier to create
customized emulations for applications that do not support
named colors completely
*
.
See www.hp.com/go/Z3200/PANTONE for detailed
information about this printer's PANTONE coverage.
* These may be RGB or CMYK values, depending on your workflow.
** For HP Professional PANTONE Emulation to work correctly, design applications must allow the assignment of the correct color name to design elements, and the name must be preserved intact
in the PostScript or PDF file passed to a supported RIP with embedded HP Professional PANTONE Emulation technology. Since ink values are calculated based on colorimetric information
present in an ICC profile, a correct and up-to-date ICC profile is required for the specific printer, inks, and media being used.
Save costs
Advanced color
management
options
Enhanced for
workgroups
and remote
management
Automatic nesting with
margin controls
In-printer processing with
embedded TIFF, JPEG,
and Adobe PS3/PDF RIP
Additional features Benefits
HP Advanced Profiling
Solution
HP Professional
PANTONE Emulation
• driverless direct job
submission
• queuing
• storage of files

HP DesignJet Z3200 Specifications

General

Color	Yes
Printing colors	Blue, Cyan, Green, Light cyan, Light magenta, Magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	12
Page description languages	PCL 3
Media thickness	0.8 mm
Roll top margin	5 mm
Maximum print size	1118 x 1676 mm
Maximum roll width	609 mm
Maximum roll length	91.4 m
Maximum roll diameter	134 mm
Minimum system requirements	Windows Vista/XP Professional/Server 2003/Server 2008 Mac OS X v 10.4/0.5/10.6
Storage media	HDD
Internal storage capacity	80 GB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T Mbit/s
Ethernet interface type	Fast Ethernet
Power requirements	100 - 240v AC, 50/60Hz
Power consumption (typical)	200 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Package weight	123 g

Weight and Dimensions

Dimensions (WxDxH)	1770 x 690 x 1047 mm
