Datasheet|HPDesignjetZ5400PostScript®ePrinter
Technical specications Ordering information
Print Printresolution Upto2400x1200optimizeddpi
Margins Roll:5x5x5x5mm(0.2x0.2x0.2x0.2in)
(borderlessonphotorollmedia);
Sheet:5x17x5x5mm(0.2x0.67x0.2x0.2in)
Inktypes Pigment-based
Lineaccuracy +/-0.1%
5
Minimumline
width
0.04mm(0.0015in)(HP-GL/2addressable)
Guaranteed
minimumline
width
0.08mm(0.0031in)(ISO/IEC13660:2001(E))
6
Image quality Shorttermcolor
stability
<1dE2000inlessthan5minutes
7
Longterm
print-to-print
repeatability
Average<0.5dE2000,95%ofcolors<1.4dE2000
7
Maximumoptical
density
4L*min/2.5D
8
Media Handling Twoautomaticrollfeeds;smartroll-switching;sheetfeed;
mediaoutputbin;automaticcutter
9
Size 210x279to1118x1676-mm(8.3x11to44x66-in)
sheets;279to1118-mm(11to44-in)rolls
Thickness Upto0.5mm(19.7mil)
Applications Linedrawings,Renderings,Maps,Orthophotos,Graphicsdesign,Oce
Graphics,Posters,Photos,Digitalneart,Banners,Exhibition,eventgraphics,
Lightboxes-lm,Pointofsale/display
Memory 64GB(virtual)
10
,320GBharddisk
Connectivity Interfaces
(standard)
GigabitEthernet(1000Base-T),Hi-SpeedUSB2.0certied,
EIOJetdirectaccessoryslot
Printlanguages
(standard)
AdobePostScript3,AdobePDF1.7,TIFF,JPEG,CALSG4,HP
PCL3GUI,HP-GL/2andHP-RTL
11
Printingpaths Printerdriver,HPEmbeddedWebServer,HPInstantPrinting
PRO,USB,emailprinting
Drivers(included) PostScriptWindowsandMacdrivers
Dimensions
(w x d x h)
Printer 1770x721x1050mm(69.7x28.4x41.3in)
Shipping 1930x770x710mm(76x30.3x28in)
Weight Printer 86kg(189lb)
Shipping 115kg(253.5lb)
What’s in the
box
HPDesignjetZ5400PostScript®ePrinter,printheads,introductoryink
cartridges,printerstandandmediabin,spindle,quickreferenceguide,setup
poster,start-upsoftware,powercord
Software
included
Printerdriver,HPInstantPrintingPROforWindows,HPPrinterUtilityincluding
HPColorCenter,HPDesignjetExcelAccountingTool
Environmental
ranges
Operatingtemp. 5to40°C(41to104°F)
Storagetemp. -25to55°C(-13to131°F)
Operating
humidity
20to80%RH(non-condensing)
Acoustic Soundpressure 45dB(A)(active);23dB(A)(standby)
Soundpower 6.7B(A)(active);4.1B(A)(standby)
Power Consumption <120watts(printing);<27watts(ready);<5watts(<22
wattswithembeddedDigitalFrontEnd)(sleep);0.1watts
(o)
Requirements Inputvoltage(autoranging)100to240VAC(+/-10%),
50/60Hz(+/-3Hz),2Amax
Certication Safety USAandCanada(CSAcertied);EU(LVDandEN60950-1
compliant);Russia/Kazakhstan(EAC);Singapore(PSB);
China(CCC);Argentina(IRAM);Mexico(NYCE)
Electromagnetic CompliantwithClassBrequirements,including:USA(FCC
rules),Canada(ICES),EU(EMCDirective),Australia(ACMA),
NewZealand(RSM),China(CCC),Japan(VCCI);Certiedas
ClassAproduct:Korea(KCC)
Environmental ENERGYSTAR;WEEE;EURoHS;ChinaRoHS;REACH
Warranty One-yearlimitedhardwarewarranty
Product E1L21A HPDesignjetZ540044-inPostScriptePrinter
Accessories CN538A HPDesignjet3-inCoreAdapter
Q6709A HPDesignjet44-inchRollFeedSpindle
J8025A HPJetdirect640nPrintServer
Original HP
printheads
C9404A HP70MatteBlackandCyanPrinthead
C9406A HP70MagentaandYellowPrinthead
C9407A HP70PhotoBlackandLightGrayPrinthead
Original HP ink
cartridges
CN629A HP772300-mlMagentaDesignjetInkCartridge
CN630A HP772300-mlYellowDesignjetInkCartridge
CN633A HP772300-mlPhotoBlackDesignjetInkCartridge
CN634A HP772300-mlLightGrayDesignjetInkCartridge
CN635A HP772300-mlMatteBlackDesignjetInkCartridge
CN636A HP772300-mlCyanDesignjetInkCartridge
C9448A HP70130-mlMatteBlackInkCartridge
C9449A HP70130-mlPhotoBlackInkCartridge
C9451A HP70130-mlLightGrayInkCartridge
C9452A HP70130-mlCyanInkCartridge
C9453A HP70130-mlMagentaInkCartridge
C9454A HP70130-mlYellowInkCartridge
Original
HP large
format printing
materials
C6810A
HPBrightWhiteInkjetPaper(FSC®certied)
12 13
914mmx91.4m(36inx300ft)
Q7996A
HPPremiumInstant-drySatinPhotoPaper(FSC®certied)
12 13
1067mmx30.5m(42inx100ft)
C0F29A HPEverydayAdhesiveGlossPolypropylene,2Pack
1067mmx22.9m(42inx75ft)
C6030C
HPHeavyweightCoatedPaper(PEFC™certied)
12 13

914mmx30.5m(36inx100ft)
C2T54A
HPPremiumMattePolypropylene,2Pack
13
1067mmx22.9m(42inx75ft)
CH025A
HPEverydayMattePolypropylene,2Pack
13
1067mmx30.5m(42inx100ft)
Service and
support
U0LZ3E HP3yearNextBusinessDayOnsitesupport
14
U0LZ6E HP3yearNextBusinessDayOnsitesupportwithDefectiveMedia
Retention
15
U0LZ8E HP3year4-hourresponse,9x5Onsitesupport
14
U0MA2PE HP1yearPostWarrantyNextBusinessDayOnsitesupport
14
U0MA3PE HP1yearPostWarrantyNextBusinessDayOnsitesupportwith
DefectiveMediaRetention
15
U0MA4PE HP1yearPostWarranty4-hourresponse,9x5OnsiteSupport
14
5
 +/-0.1%ofthespeciedvectorlengthor+/-0.2mm(whichevergreater)at23ºC(73ºF),
50-60%relativehumidity,onA0/EHPMatteFilminBestorNormalmodewithHPPhotoInks.
6
 MeasuredonHPMatteFilm.
7
 WithHPPremiumInstantDryPhotoSatinmediawithHPPhotoInks,rightaftercalibration.
8
 WithHPPremiumInstantDryPhotoGlossmediawithHPPhotoInks.
9
 Cutsallmediaexceptcanvasandbanners.
10
Basedon640MBRAM.
11
OnlyavailableviaHPInstantPrintingPROortheHPEmbeddedWebServer.
12
 FSC®trademarklicensecodeFSC®-C017543,seefsc.org.PEFC™trademarklicensecodePEFC™/29-
31-198,seepefc.org.NotallFSC®-orPEFC™-certiedproductsareavailableinallregions.
13
HPLargeFormatMediatake-backprogramavailabilityvaries.Recyclingprogramsmaynotexistin
yourarea.Seehp.com/recyclefordetails.
14
NotavailableinNorthAmericaandLatinAmerica.
15
NotavailableinEurope,MiddleEast,andAfrica.
For more information, please visit
hp.com/go/DesignjetZ5400
©Copyright2013Hewlett-PackardDevelopmentCompany,L.P.Theinformationcontainedhereinissubjecttochangewithoutnotice.Theonlywarrantiesfor
HPproductsandservicesaresetforthintheexpresswarrantystatementsaccompanyingsuchproductsandservices.Nothinghereinshouldbeconstruedas
constitutinganadditionalwarranty.HPshallnotbeliablefortechnicaloreditorialerrorsoromissionscontainedherein.
AdobeandAdobePostScript3aretrademarksofAdobeSystemsIncorporated.ENERGYSTARandtheENERGYSTARmarkareregisteredU.S.marks.Windowsis
aU.S.registeredtrademarkofMicrosoftCorporation.MacandtheMaclogoaretrademarksofAppleComputer,Inc.,registeredintheU.S.andothercountries.
4AA4-7154ENW,September2013

HP Designjet Z5400 PostScript Specifications

Print Specifications

print resolution	2400 x 1200 optimized dpi
margins roll	5 x 5 x 5 x 5 mm (0.2 x 0.2 x 0.2 x 0.2 in)
margins sheet	5 x 17 x 5 x 5 mm (0.2 x 0.67 x 0.2 x 0.2 in)

Image Quality

minimum line width	0.04 mm (0.0015 in)
guaranteed minimum line width	0.08 mm (0.0031 in)
maximum optical density	4 L* min/2.5 D

Media Handling

media size	210 x 279 to 1118 x 1676 mm (8.3 x 11 to 44 x 66 in)
media thickness	Up to 0.5 mm (19.7 mil)
media handling features	Two automatic roll feeds, smart roll-switching, sheet feed, media output bin, automatic cutter

Operating Environment

operating temperature	5 to 40°C (41 to 104°F)
storage temperature	-25 to 55°C (-13 to 131°F)
operating humidity	20 to 80% RH (non-condensing)

Acoustic

sound pressure (active)	45 dB(A)
sound pressure (standby)	23 dB(A)
sound power (active)	6.7 B(A)
sound power (standby)	4.1 B(A)

Power

power consumption (printing)	< 120 watts
power consumption (ready)	< 27 watts
power consumption (sleep)	< 5 watts

Weight and Dimensions

printer dimensions	1770 x 721 x 1050 mm (69.7 x 28.4 x 41.3 in)
shipping dimensions	1930 x 770 x 710 mm (76 x 30.3 x 28 in)
printer weight	86 kg (189 lb)
shipping weight	115 kg (253.5 lb)
