Service Utilities 149
Tests and Utilities
2. In the Service Utilities submenu, scroll to ###### and press Enter.
3. At the end of the test the Front Panel will display the results:
Compare the value of L seen in the Front Panel to the results that should be seen in the following
media:
If for example the value seen in the results for L is 93 when HP Bright White media is loaded, this
would indicate that the Spectrophotometer is functioning correctly. The nominal values are shown
here for infomation only:
Paper Min L* Max L* Nominal L*
HP Bright White 90.12 95.70 91.91
HP Premium Instant Dry Gloss 92.38 97.24 93.81
HP Premium Instant Dry Photo Satin 92.13 97.36 93.74
HP Universal Coated 89.51 94.65 91.08
HP Universal Heavy Weight Coated 88.38 96.55 91.46
HP Universal Instant Dry Gloss 90.95 96.71 92.83
