222 Chapter 7 Parts and Diagrams
Parts and Diagrams
Printer Support
Reference
on
Figure
HP Part
Number
Part Description Size
Page
a
a. Refers to the page in the Removal and Installation Chapter (if applicable)
1
Q6651-60257 Leg Cover All N/A
2
Q6651-60254 Foot Assembly All N/A
3
Q6651-60260
Bin Assembly (Includes the Bin Support)
42-inch N/A
Q6652-60135
60-
inch
N/A
4
Q6651-60259
Foot Brace Assembly
42-inch N/A
Q6651-60262
60-
inch
N/A
5
Q6651-60255 Legs Assembly All N/A
6
Q6651-60258
Cross-Brace Assembly
42-inch N/A
Q6651-60261
60-
inch
N/A
7
Q6651-60355 Stand Supports All N/A
-
Q6651-60256
Hardware Kit (Includes screws for Legs
Assembly)
All N/A
