260 Chapter 8 Removal & Installation
Removal & Installation
Window (42-inch)
Removal
1. Open the Window.
2. Unclip the Window hinges from the Top Cover.
3.
Remove the Window from the Printer.
WARNING!: Switch off the printer and remove the power cable.
NOTE: Throughout this section the graphics actually show the HP Designjet 4000 Printer series but the
steps of the procedure are identical for the HP Designjet Z6000 Printer series.
NOTE: Since the hinges are very hard to
unclip, it is recommended that you use a
screwdriver or other tool to forcefully unclip the
Window hinges from the Top Cover.
To Next Page
