418 Chapter 8 Removal & Installation
Removal & Installation
6. Release the Encoder Sensor cable from the clip located
on the Encoder Disc Cover.
7. Unclip the Encoder Disc Cover and remove from the
Printer.
8. Remove one T-8 screw (Type D) that secures the
Encoder Sensor to the Chassis.
9. Remove the Encoder Sensor from the Printer.
To Next Page
