HP Designjet Z6200 Photo Printer series
Technical specifications
Print
Line Drawings 17 sec/page on A1/D
Colour images CQ109A: 108 m²/hr on coated media; 16.4 m²/hr on glossy media
CQ111A: 128.5 m²/hr on coated media; 19.7 m²/hr on glossy media
Print speed 140 m²/hr; Mechanical printing time. Printed in Fast mode with Economode on, using HP Bright
White Inkjet Paper (Bond). Measured on a 60-in printer.
Print resolution Up to 2400 x 1200 optimized dpi
Margins (top x bottom x left x right) Roll: 5 mm (top), 5 mm (right), 5 mm (left), 5 mm (bottom)
Technology HP Thermal Inkjet
Ink types Pigment-based
Ink colours 8 (chromatic red, magenta, matte black, photo black, yellow, light cyan, light grey, light magenta)
Ink drop 4 pl (lc, lm, lg, pK), 6 pl (R, M, Y, mK)
Print head nozzles 2112
Print heads 8 (chromatic red, magenta, matte black, photo black, yellow, light cyan, light grey, light magenta)
Line accuracy +/- 0.1% (+/- 0.1% of the specified vector length or +/- 0.2 mm (whichever greater) at 23º
C,50-60% relative humidity, on A0/E printing material in Best or Normal mode with HP Matte
Film)
Minimum line width 0.02 mm (HP-GL/2 addressable); measured on HP Matte Film.
Guaranteed minimum line width 0.067 mm (ISO/IEC 13660:2001(E)); measured on HP Matte Film.
Maximum print length 175 m
Maximum optical density 2.31 maximum black optical density (4.5 L* min) (with HP Premium Instant Dry Photo Gloss
media with Original HP inks)
Media
Types Bond and coated paper, technical paper, film, photographic paper, proofing paper, backlit,
self-adhesive, banner and sign, fabric, fine art printing material
Weight Up to 460 g/m² depending on media type
Thickness Up to 0.56 mm
Memory
Standard 32 GB, Based on 1 GB RAM, Expandable to 1.5 GB RAM through a Designjet qualified SODIMM
included only in the optional HP Designjet PostScript®/PDF Upgrade Kit accessory
Hard disk Standard, 160 GB
Connectivity
Interfaces (standard) Gigabit Ethernet (1000Base-T); EIO Jetdirect accessory slot; Hi-Speed USB 2.0
Interfaces (optional) Compatible HP Jetdirect LAN cards
Print languages (standard) HP-GL/2, HP-RTL, CALS G4
Print languages (optional) Adobe® PostScript® 3; Adobe® PDF 1.7; TIFF; JPEG
Drivers included HP-GL/2, HP-RTL drivers for Windows® (optimised for AutoCAD 2000 and higher); PostScript®
Windows®, Linux, and Mac drivers with optional PostScript®/PDF Upgrade Kit
Operating systems compatibility
Windows® 7 Ultimate/Professional/Home Premium; Windows Vista® Ultimate/Business/Home
Premium; Microsoft® Windows® XP (32-bit, 64-bit) Professional/Home, Server 2008 (32-bit,
64-bit), Server 2003 (32-bit, 64-bit); Mac OS X v10.4, v10.5, v10.6 (with optional PostScript/PDF
upgrade); Citrix XenApp; Citrix XenServer
Recommended system requirements
Mac Mac OS X v10.4, v10.5: PowerPC G3 or Intel® Core processor, 246 MB RAM, 1 GB available hard
disk space; Mac OS X v10.6: Mac computer with Intel® Core processor, 1 GB RAM, 2 GB available
hard disk space
Windows Windows® 7: 32-bit (x86) or 64-bit (x64) processor (1 GHz), 1 GB RAM (32-bit) or 2 GB RAM
(64-bit), 2 GB available hard disk space; Windows Vista® Ultimate/Business/Home Premium:
32-bit (x86) or 64-bit (x64) processor (1 GHz), 1 GB RAM; 2 GB available hard disk space;
Microsoft® Windows® XP Professional/Home (SP2 or higher): Intel® Pentium® family or AMD
K6™/Athlon™/Duron™ family (1 GHz); 512 MB RAM; 2 GB available hard disk space
Environmental ranges
Operating temperature 5 to 40ºC
Storage temperature -20 to 55ºC
Operating humidity 20 to 80% RH
Storage humidity 20 to 80% RH
Acoustic
Sound Pressure 53 dB(A), 38 dB(A) (standby)
Sound Power 7.0 B(A), 5.8 B(A) (standby)
What's in the box
CQ109A HP Designjet Z6200 1067 mm (42-in) Printer; spindle; printheads; introductory ink cartridges;
maintenance cartridge; Original HP media sample roll; printer stand; media bin; 7.62 cm (3-in)
spindle adaptor kit; quick reference guide; setup poster; startup software; power cord
CQ111A HP Designjet Z6200 1524 mm (60-in) Printer; spindle; printheads; introductory ink cartridges;
maintenance cartridge; Original HP media sample roll; printer stand; loading table; Take-Up
Reel; 7.62 cm (3-in) spindle adaptor kit; quick reference guide; setup poster; startup software;
power cord
Dimensions (w x d x h)
Printer CQ109A: 1970 x 690 x 1370 mm; CQ111A: 2430 x 690 x 1370 mm;
Packaged CQ109A: 2230 x 750 x 1200 mm; CQ111A: 2690 x 750 x 1200 mm;
Weight
Printer CQ109A: 123 kg; CQ111A: 190 kg;
Packaged CQ109A: 210 kg; CQ111A: 250 kg;
Power consumption
Maximum 420 watts maximum, 270 watts (active), <100 watts (standby), <9 watts/<46 watts with
embedded Digital Front End (sleep), <0.5 watts (manual off)
Power requirements Input voltage (auto ranging): 100 to 127 VAC (+/- 10%), 5 A; 220 to 240 VAC (+/- 10%), 3 A;
50/60 Hz (+/- 3 Hz)
Certification
Safety EU (LVD and EN 60950-1 compliant); Russia (GOST)
Electromagnetic Compliant with Class A requirements, including EU (EMC Directive)
Environmental ENERGY STAR®; WEEE; EU RoHS; REACH; FEMP
ENERGY STAR Yes
Warranty
Standard warranty: one year, next business day on-site support. Warranty and support options
vary by product, country and local legal requirements.
Ordering information
Product
CQ109A HP Designjet Z6200 1067 mm Photo Printer
CQ111A HP Designjet Z6200 1524 mm Photo Printer
Accessories
CQ745A HP Designjet PostScript/PDF Upgrade Kit
CQ752A HP Designjet Z6200 1067mm Take-Up Reel
CQ753A HP Designjet Z6200 1067mm Spindle
CQ754A HP Designjet Z6200 1524 mm Spindle
Q6714A HP Designjet 1524mm Media Bin
CQ654B HP Designjet HD Scanner
J8025A HP Jetdirect 640n Print Server
Ink supplies
CH644A HP 771 Designjet Maintenance Cartridge
CE017A HP 771 Matte Black/Chromatic Red Designjet Printhead
CE018A HP 771 Magenta/Yellow Designjet Printhead
CE019A HP 771 Light Magenta/Light Cyan Designjet Printhead
CE020A HP 771 Photo Black/Light Gray Designjet Printhead
B6Y07A HP 771C 775-ml Matte Black Designjet Ink Cartridge
B6Y08A HP 771C 775-ml Chromatic Red Designjet Ink Cartridge
B6Y09A HP 771C 775-ml Magenta Designjet Ink Cartridge
B6Y10A HP 771C 775-ml Yellow Designjet Ink Cartridge
B6Y11A HP 771C 775-ml Light Magenta Designjet Ink Cartridge
B6Y12A HP 771C 775-ml Light Cyan Designjet Ink Cartridge
B6Y13A HP 771C 775-ml Photo Black Designjet Ink Cartridge
B6Y14A HP 771C 775-ml Light Gray Designjet Ink Cartridge
B6Y31A HP 771C 3-pack 775-ml Matte Black Designjet Ink Cartridges
B6Y32A HP 771C 3-pack 775-ml Chromatic Red Designjet Ink Cartridges
B6Y33A HP 771C 3-pack 775-ml Magenta Designjet Ink Cartridges
B6Y34A HP 771C 3-pack 775-ml Yellow Designjet Ink Cartridges
B6Y35A HP 771C 3-pack 775-ml Light Magenta Designjet Ink Cartridges
B6Y36A HP 771C 3-pack 775-ml Light Cyan Designjet Ink Cartridges
B6Y37A HP 771C 3-pack 775-ml Photo Black Designjet Ink Cartridges
B6Y38A HP 771C 3-pack 775-ml Light Gray Designjet Ink Cartridges
Media supplies
Q8748A HP Premium Vivid Color Backlit Film-1067 mm x 30.5 m (42 in x 100 ft)
Q8674A HP Professional Matte Canvas-1067 mm x 15.2 m (42 in x 50 ft)
Q1899B HP Opaque Scrim-1067 mm x 15.2 m (42 in x 50 ft)
C6036A HP Bright White Inkjet Paper-914 mm x 45.7 m
Q1398A HP Universal Bond Paper-1067 mm x 45.7 m (42 in x 150 ft)
Q1907A HP Matte Polypropylene-1524 mm x 22.9 m (60 in x 75 ft)
CG460A HP Premium Matte Photo Paper-914 mm x 30.5 m (36 in x 100 ft)
Service & support
UV289E HP Care Pack, Next Business Day Designjet Z6200 1067mm Hardware Support, 3 years
UX868E HP Care Pack, Next Business Day Designjet Z6200 1067mm Hardware Support, 4 years
UX869E HP Care Pack, Next Business Day Designjet Z6200 1067mm Hardware Support, 5 years
UV291E HP Care Pack, 4 Hour Response Time 13x5 Designjet Z6200 1067mm Hardware Support, 3 years
UX879PE HP Care Pack, Post Warranty Next Business Day Designjet Z6200 1067mm Hardware Support, 1 year
UX876PE HP Care Pack, Post Warranty Next Business Day Designjet Z6200 1067mm Hardware Support, 2 years
UX878PE HP Care Pack, Post Warranty 4 Hour Response Time 13x5 Designjet Z6200 1067mm Hardware Support, 1 year
H4518E HP Care Pack, Network Install Designjet T23-71XX, 400-6200 SVC
Count on dependable support to create the best image possible. We can help you enhance your printing and
imaging environment, protect your IT investment, and grow your business—with expert support that’s affordable,
personal, and tailored to your needs through HP Care Pack Services.
For more information, please visit http://www.hp.com/designjetZ6200
For more HP Large Format Media substrates and sizes please visit us online at: http://www.hp.com/go/designjet/supplies
© Copyright 2010 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
4AA2-4324EEE Published in EMEA August 2013
