WARNING! Switch off the printer and remove the power cable.
1. Remove the Right Cover See Right Cover on page 216.
2. Remove the Left Cover
See Left Cover on page 222.
3. Remove the Rear Door
See Rear Door (60-inch) on page 237.
4. Release the clip securing the Ink Supply Tubes and the Trailing Cable to the Top Cover.
5. Release the Ink Supply Tubes and Trailing Cable from the clip underneath the Top Cover.
6. Press the clip to release it from the Top Cover.
230 Chapter 8 Removal and installation ENWW
Removal and
installation
