HP Designjet Z6200

HP 771 Red 775 ml Ink Cartridge CE038A
HP 771 Magenta 775 ml Ink Cartridge CE039A
HP 771 Yellow 775 ml Ink Cartridge CE040A
HP 771 Light Magenta 775 ml Ink Cartridge CE041A
HP 771 Light Cyan 775 ml Ink Cartridge CE042A
HP 771 Photo Black 775 ml Ink Cartridge CE043A
HP 771 Light Gray 775 ml Ink Cartridge CE044A
Printheads
The printheads are connected to the ink cartridges. They use jet action to put ink on the paper. Each
printhead has two ink cartridge connection points and two jet nozzles, which means that each
printhead accommodates two ink cartridges. For example, the following printhead image indicates a
printhead that draws and jets ink from the magenta and yellow cartridges.
The Printheads are extremely durable and do not need to be replaced every time an Ink Cartridge is
replaced. They are independent of the Ink Cartridges and will continue giving excellent image quality
results even if the Ink Cartridges are low on ink.
If you notice a decline in print quality such as lines or dots missing from text/graphics, go to
Initial
print-quality troubleshooting actions on page 147.
The following table lists the Printheads for the HP Designjet Z6200 Photo printer series.
Description Part number
HP 771 Matte Black & Red Printhead CE017A
HP 771 Magenta & Yellow Printhead CE018A
HP 771 Light Magenta & Light Cyan Printhead CE019A
HP 771 Photo Black & Light Gray Printhead CE020A
Maintenance Cartridge
Use the Maintenance Cartridge to clean and maintain the Printheads, ensure the best possible print
quality, and seal the Printheads when they are not in use to prevent them from drying out.
