HP DL320 - ProLiant - G3 - Page 21

hp ProLiant DL320 generation 2 server high-density deployment technical white paper 21
24 Port Switch (24 GbE) 6
48 Port Switch (44 FE + 4 GbE)
24 Port Switch (24 GbE) 5
24 Port Switch (24 GbE) 4
14 x GbE
24 Port Switch (24 GbE) 3
24 Port Switch (24 GbE) 2
24 Port Switch (24 GbE) 1
Server 01
Server 02
Server 03
Server 14
Server 15
Server 28
Server 29
Server 42
64x Cat 5
Uplink to Network
Backbone
14 x GbE 14 x GbE 14 x GbE 14 x GbE 14 x GbE 42 x GbE
10x GbE
4x GbE
105 x Cat 5 Cables Routed Outside Server Cabinet
NI
C
1
(Gb
E
)
NI
C
2
(Gb
E
)
iL
O
(
FE
)
Servers in Rack
Switches in Another Rack
Figure 3. Configuration A (Maximum Performance Density) Ethernet Cable Diagram
Note: There are no KVM Switches used in Configuration A. The Integrated Lights-Out
Advanced Pack handles all of the local consoles. See Figure 2 for the Ethernet Cable Diagram.
