hp ProLiant DL320 generation 2 server high-density deployment technical white paper 29
3x KVM
Cables
(switch to
switch)
2x KVM Cables
1x KVM Cables
24 Port Hub (24 FE) 2
48 Port Switch (44 FE + 4 GbE) 1
48 Port Switch (44 FE + 4 GbE) 2
KVM Switch
Server 01
Server 02
Server 03
Server 04
Server 05
Server 06
Server 07
Server 08
KVM Switch
Server 09
Server 10
Server 11
Server 12
Server 13
24 A PDU
24 A PDU
KVM Switch
1U Keyboard/Monitor
Server 14
Server 15
Server 16
Server 17
Server 18
Server 19
Server 20
KVM Switch
Server 21
Server 22
Server 23
Server 24
Server 25
Server 26
Server 27
Server 28
24 A PDU
24 A PDU
24 Port Hub (24 FE) 1
blank
8x KVM Cables5x KVM Cables7x KVM Cables8x KVM Cables
4x KVM cables
switch to switch
28x KVM cables
switch to server
Figure 9. Configuration C (Traditionalist) KVM Diagram
